CNC-TURNING EQUIPMENT

DAEWOO LYNX-2100A 2018

CNC-LATHE
2.00 DIA THRU
12” SWING
13” TURNING LENGTH
CHIP CONVEYOR
WITH LNS SERVO 80 BARFEED

DAEWOO LYNX-2100A 2017

CNC-LATHE
2.00 DIA THRU
12” SWING
13” TURNING LENGTH
CHIP CONVEYOR
WITH LNS SERVO 80 BARFEED

HAAS “SL-30T” TURNING CENTER 2001

3″ DIA THRU
30″ SWING OVER APRON
34″ TURNING LENGTH



DOOSAN “TT 2500 SY” TWIN TURRET, TWIN SPINDLE TURNING CENTER 2005

This machine is designed for completing first and second turning operations in one actual loading. A workpiece may be loaded to the first spindle, turned and then automatically and internally transferred to the second spindle for second operation turning.

3.0″ DIA THRU
31.5″ SWING OVER BED
29.13″ TURNING LENGTH
CHIP CONVEYOR

ARCADE GUN DRILL AND CENTRIFUGE

1/8” TO 1-1/4” DIA X 24” LONG
4200 RPM

WARNER SWASEY CHUCKER

2AC MODEL M3200

MORI-SEIKI SL-7B

MAX SWING OVER BED 35.83”
MAX SWING OVER CARRIAGE 22.83”
DISTANCE BETWEEN CENTERS 68.90”
3” DIA THRU
12 TOOL TURRET

MAZAK QUICK TURN 18N

2.75” DIA THRU
10” SWING
TURNING LENGTH

MAZAK QUICK TURN 20-UNIVERSAL

2.5” DIA THRU
11.8” SWING
40.76” TURNING LENGTH

MAZAK SUPER QUICK TURN 30M

MAZAK SUPER QUICK TURN 30M WITH LIVE TOOLING
3” DIA THRU
16.25” SWING
39.56” TURNING LENGTH

DAEWOO LYNX-220A 2010

CNC-LATHE
1.750 DIA THRU
11” SWING
13” TURNING LENGTH
CHIP CONVEYOR
WITH LNS SERVO 80 BARFEED

DAEWOO LYNX-220A 2008

CNC-LATHE
1.750 DIA THRU
11” SWING
13” TURNING LENGTH
CHIP CONVEYOR
WITH LNS SERVO 80 BARFEED

DAEWOO LYNX-210A 2006

CNC-LATHE
1.750 DIA THRU
11” SWING
13” TURNING LENGTH
CHIP CONVEYOR
WITH LNS SERVO 65 BARFEED

DAEWOO LYNX-210A 2004

CNC-LATHE
1.750 DIA THRU
11” SWING
13” TURNING LENGTH
TAIL STOCK & CHIP CONVEYOR
WITH LNS SERVO 65 BARFEED

DAEWOO LYNX-200A 1998

CNC-LATHE
1.750 DIA THRU
11” SWING
13” TURNING LENGTH
TAIL STOCK & CHIP CONVEYOR

MANUAL TURNING EQUIPMENT

(3) HARDINGE HAND SCREWS

NEW 1966/1968
MODEL DV 59 SECOND OP LATHES

EMCO-MAIER TOOL ROOM LATHE

NEW 1997
MODEL V13
10” SWING / 26” BETWEEN CENTERS

MANUAL MILLING EQUIPMENT

CHEVALIER MANUAL MILL 1998

NEW
MODEL FM-3VKH
TABLE SIZE = 10” X 50”

CHEVALIER MANUAL MILL 1997

NEW
MODEL FM-3VS
TABLE SIZE = 10” X 50”

CNC-MILL EQUIPMENT

HAAS VF2 SS CNC VERTICAL MILL

40 Taper Spindle
Travels = 30.0 X / 16.0 Y / 20.0 Z

HAAS VF4 SS CNC VERTICAL MILL 2014

THRU COOLANT CAPABILITIES
REINSHAW PROBING
TRAVELS = 50.0 X / 20 Y / 26.0 Z

HAAS VF3 SS CNC VERTICAL MILL 2005

40 Taper Spindle
Travels = 40.0 X / 20.0 Y / 25.0 Z

HAAS VF3 SS CNC VERTICAL MILL 2006

40 Taper Spindle
Travels = 40.0 X / 20.0 Y / 25.0 Z

HAAS VF2 SS CNC VERTICAL MILL 2004

40 Taper Spindle
Travels = 30.0 X / 16.0 Y / 20.0 Z
Part Probe

HAAS VF3 SS CNC VERTICAL MILL 2005

40 Taper Spindle
Travels = 40.0 X / 20.0 Y / 25.0 Z

HAAS VF2 SS CNC VERTICAL MILL 2010

40 Taper Spindle
Travels = 30.0 X / 16.0 Y / 20.0 Z

HAAS VF2 SS CNC VERTICAL MILL 2008

40 Taper Spindle
Travels = 30.0 X / 16.0 Y / 20.0 Z

HAAS VF3 SS CNC VERTICAL MILL 2004

NEW
40 TAPER SPINDLE
TRAVELS = 40.0 X / 20.0 Y / 25.0 Z

FANUC ROBODRILL CNC-MILL 1998

NEW
MODEL T14IA
30 TAPER SPINDLE
TRAVELS = 19.0 X / 15.0 Y / 12.0 Z

HAAS VF4 SS CNC VERTICAL MILL 2004

NEW
40 TAPER SPINDLE
TRAVELS = 50.0 X / 20.0 Y / 25.0 Z

HAAS VF4 SS CNC VERTICAL MILL 2007

NEW
40 TAPER SPINDLE
TRAVELS = 50.0 X / 20.0 Y / 25.0 Z

HAAS VF4 SS CNC VERTICAL MILL 2007

NEW
40 TAPER SPINDLE
TRAVELS = 40.0 X / 20.0 Y / 25.0 Z

MAZAK H500 HORIZONTAL MILL

50 TAPER SPINDLE
TRAVELS = 27.95 X / 25.59 Y / 25.59 Z
EQUIPED WITH 2 PALLETS
1 DEGREE INDEXING TOMBSTONES

MAZAK H-22 HORIZTONAL MILL

50 TAPER SPINDLE
TRAVELS = 43.3 X / 42.1 Y / 29.5 Z
EQUIPED WITH 2 PALLETS

HAAS VF4 CNC VERTICAL MILL 2006

40 TAPER SPINDLE
TRAVELS = 50.0 X / 20.0 Y / 24.0 Z

HAAS VF3 CNC VERTICAL MILL 2003

40 TAPER SPINDLE
TRAVELS = 40.0 X / 20.0 Y / 24.0 Z

HAAS VF 2 CNC VERTICAL MILL 2001

40 TAPER SPINDLE
TRAVELS = 30.0 X / 15.0 Y / 19.94 Z

MAZAK MTV-515/40N CNC VERTICAL MILL

50 TAPER SPINDLE
TRAVELS = 41.32 X / 20.07 Y / 22.04 Z

MAZAK AJV-25/405 CNC VERTICAL MILL

50 TAPER SPINDLE
TRAVELS = 39.4 X / 20 Y / 18.1 Z

MAZAK VQ20/50B CNC VERTICAL MILL

50 TAPER SPINDLE
TRAVELS = 39.37 X / 20 Y / 18.1 Z

HAAS VF4 SS CNC VERTICAL MILL 2015

NEW
THRU COOLANT CAPABILITIES
REINSHAW PROBING
TRAVELS = 50.0 X / 20 Y / 26.0 Z
MIDACO AS5020SD PALLET CHANGER EQUIPPED
WITH 2 PALLETS
2 – 4 th AXIS ROTARY’S MOUNTED ON 2 MILLS

HAAS VF4 SS CNC VERTICAL MILL 2013

NEW
THRU COOLANT CAPABILITIES
REINSHAW PROBING
TRAVELS = 50.0 X / 20 Y / 26.0 Z

CNC-SAW

COSAN C-260NC 2012

NEW
W/AUTOMATIC PART COUNT
FULL ROLLER STAGING CONVEYOR

COSAN C-260NC 2012

NEW
W/AUTOMATIC PART COUNT
FULL ROLLER STAGING CONVEYOR

CNC-C02 LASER

MITSUBISHI ML3015NX
4500 WATT 5’x10′ TABLE
W/ TORIT DUST COLLECTOR
FULLY AUTOMATED WITH TOWER
UP TO 1″ STEEL CAPABILITIES
ABLE TO RUN LIGHTS OUT FOR HIGH PRODUCTION ORDERS

FORMING

DURMA MRB 1204 MOTORIZED ROLLER

4′ WIDE OPENING
7″ ROUND CAPABILITIES

CHICAGO D&K MECHANICAL BRAKE

45 TON – 4’ OPENING
W/PROGRAMMABLE BACK GATE

CHICAGO D&K MECHANICAL BRAKE

45 TON – 6’ OPENING
WITH PROGRAMMABLE BACK GATE

ACCUPRESS BRAKE

130 TON – 12’ OPENING
WITH PROGRAMMABLE BACK GATE

WELDING

MILLERMATIC 252 WIRE FEED
MILLERMATIC 210 WIRE FEED
MILLERMATIC 350P MIG WELDER WITH PULSE CAPABILITIES
BP-2 WELDING POSITIONER WITH VARIABLE SPEED
ESAB 353 CV MIG WELDER
ESAB V-352 DUAL HEAD MIG WELDER
LINCOLN 375 TIG WELDER
LINCOLN 350 MIG WELDER

TIMESAVING

16” TIME SAVER

BEAD BLASTING

2’ X 3’ GLASS BEAD BLASTER

ASSEMBLIES

MECHANICAL & ELECTRICAL ASSEMBLIES

LASER ETCHING

ELECTROX

BED SIZE 24 X 18 (Doors can be open to unlimited space)
20 WATT FIBER

PROGRAMMING CAPABILITIES

VELLUM / GIBBSCAM 2012+

FOR CNC TURNING AND CNC MILLING

NOTE: CAN ACCEPT .IGS, .DXF, .DWG AND SEVERAL OTHER GEOMETRY FORMATS

VELLUM / GEOM-TOOL FOR CO2 LASER

NOTE: CAN ACCEPT .IGS, .DXF, .DWG AND SEVERAL OTHER GEOMETRY FORMATS

SOLID WORKS PROFESSIONAL 2015

NOTE: CAN ACCEPT .IGS, .DXF, .DWG AND SEVERAL OTHER GEOMETRY FORMATS

MANUAL SUPPORT EQUIPMENT

SCOTCHMAN COLD SAW NEW 2005 MODEL CPO 350
MITSUBISHI 500 LB. FORKLIFT NEW 1996
CLARK 4500 LB. FORKLIFT NEW 1994
HYSTER 2500 LB. FORKLIFT NEW 1950
TMC 6000 LB. FORKLIFT NEW 2006
(2) ULTRAMATIC TUMBLERS NEW 2002/2004
ROTOFINISH TUMBLER NEW 2000
DELTA CUSTOM-BUILT HIGH SPEED PLASTIC SAW 12” CARBIDE BLADE
PJ 25’ FIFTH-WHEEL TRAILER NEW 2006

FOR SPECIAL PART DELIVERY

OTHER FACILITIES

*POWDERCOATING
*PAINTING
*PLATING
*HEAT TREATING
*WATERJET CUTTING
*FLAME CUTTING
*TUBE BENDING
*PACKAGING IN YOUR BOXES IF NECESSARY
*BLIND SHIPMENTS
